Pearson 7305 监测器
型号：7305
Sensitivity 1.0 Volt/Ampere ±1 %
Output resistance 50 Ohm
Maximum peak current 500 Ampere
Maximum rms current 7.5 Amperes
Droop rate 0.08 %/microsecond
Useable rise time 20 nanoseconds
Current time product 0.005 Ampere-second max.*
Low frequency 3dB cut-off 125 Hz (approximate)
High frequency 3dB cut-off 20 MHz (approximate)
I/f figure 0.017 peak Amperes/Hz
Output connector BNC (UG-657A/U)
Shielding Double
