10Gb/s 1310nm SFP+ 40km Transceiver
Product Features
l Up
to 11.1Gbps Data Links
l Up
to 40km transmission on SMF
l DFB Laser and PIN receiver
l Metal enclosure, for lower EMI
l 2-wire
interface with integrated Digital Diagnostic monitoring
l Hot-pluggable SFP+ footprint
l Specifications compliant with SFF 8472
l Compliant
with SFP+ MSA with LC connector
l Single 3.3V power supply
l Case operating temperature range:0°C to 70°C
l Power
dissipation < 1.5 W
Applications
l 10GBASE-ER/EW
& 10G Ethernet
Standard
l Compliant to SFF-8431
l Compliant to SFF 8472
l RoHS Compliant.
Absolute Maximum Ratings
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Storage Temperature
Ts
-40
-
85
oC
Storage Ambient
Humidity
HA
5
-
95
%
Operating Relative
Humidity
RH
-
-
85
%
Power Supply Voltage
VCC
-0.3
-
4
V
Signal Input Voltage
Vcc-0.3
-
Vcc+0.3
V
Recommended Operating
Conditions
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Case Operating
Temperature
Tcase
0
-
70
oC
Without air flow
Power Supply Voltage
VCC
3.14
3.3
3.47
V
Power Supply Current
ICC
-
350
mA
Data Rate
BR
10.3125
Gbps
Transmission Distance
TD
-
40
km
Coupled fiber
Single mode fiber
9/125um SMF
Optical Characteristics
Parameter
Symbol
Min
Typ
Max
Unit
NOTE
Transmitter
Output Opt. Pwr
POUT
-1
4
dBm
1
Optical Wavelength
λ
1260
1310
1355
nm
Spectral Width (-20dB)
σ
1
nm
Optical Extinction Ratio
ER
4.5
dB
Transmitter and Dispersion Penalty
TDP
3
dB
Output Eye Mask
Compliant
with IEEE 0802.3ae
Receiver
Rx Sensitivity
RSENS
-15
dBm
2
Input Saturation Power
(Overload)
Psat
0.5
dBm
Wavelength Range
λC
1270
1610
nm
LOS De -Assert
LOSD
-17
dBm
LOS Assert
LOSA
-30
dBm
LOS Hysteresis
0.5
1.0
dB
05
