10Gb/s BIDI SFP+ 40km Transceiver
Product
Features
l
Up to 11.1Gbps Data Links
l
Up to 40km transmission on SMF
l
Power dissipation<1.5W
l
1270nm DFB laser and PIN receiver for HTFPPB-273396-40D
l
1330nm DFB laser and PIN receiver for HTFPPB-332796-40D
l
2-wire interface with integrated Digital Diagnostic monitoring
l
EEPROM with Serial ID Functionality
l
Hot-pluggable SFP+ footprint
l
Compliant with SFP+ MSA with LC connector
l
Single + 3.3V Power Supply
l
Case operating temperature: 0oC~+70oC
Applications
l
10GBASE-BX
Standard
l
Compliant with SFF-8472
l
Compliant to SFF-8431
l
Compliant to 802.3ae 10GBASE-ER/EW
l RoHS Compliant.
Absolute
Maximum Ratings
HTFPPB-XXYY96-40BD is hot pluggable 3.3V Small-Form-Factor transceiver
module. It designed expressly for high-speed communication applications that
require rates up to 11.1Gb/s,it designed to be compliant with SFF-8472 SFP+
MSA. The module data link up to 40km in 9/125um single mode fiber.
Absolute Maximum
Ratings
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Storage Temperature
Ts
-40
-
85
oC
Storage Ambient Humidity
HA
5
-
95
%
Operating Relative Humidity
RH
-
-
85
%
Power Supply Voltage
VCC
-0.3
-
4
V
Signal Input Voltage
Vcc-0.3
-
Vcc+0.3
V
Recommended Operating
Conditions
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Case Operating Temperature
Tcase
0
-
70
oC
Without air flow
Power Supply Voltage
VCC
3.14
3.3
3.47
V
Power Supply Current
ICC
-
450
mA
Data Rate
BR
10.3125
Gbps
Transmission Distance
TD
-
40
km
Coupled fiber
Single mode fiber
9/125um SMF
Optical
Characteristics
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Transmitter
Average Launched Power
Pout
0
-
5
dBm
Average Launched Power(Laser Off)
Poff
-
-
-30
dBm
Note 1
Center Wavelength Range
λC
1260
1270
1280
nm
HTFPPB-XXYY96-40BD
1320
1330
1340
nm
HTFPPB-XXYY96-40BD
Side mode suppression ratio
SMSR
30
-
-
dB
Spectrum Bandwidth(-20dB)
σ
-
-
1
nm
Extinction Ratio
ER
3.5
-
dB
Note 2
Output Eye Mask
Compliant with IEEE 802.3ae
Note 2
Receiver
Input Optical Wavelength
λIN
1320
1330
1340
nm
HTFPPB-XXYY96-40BD
1260
1270
1280
nm
HTFPPB-XXYY96-40BD
Receiver Sensitivity
Psen
-
-
-15
dBm
Note 3
Input Saturation Power (Overload)
PSAT
0.5
-
-
dBm
Note 3
LOS -Assert Power
PA
-30
-
-
dBm
LOS -Deassert Power
PD
-
-
-17
dBm
LOS -Hysteresis
PHys
0.5
-
5
dB
Note:
1.
The optical power is launched into SMF
2.
Measured with RPBS 2^31-1 test pattern @10.3125Gbs
3.
Measured with RPBS 2^31-1 test pattern @10.3125Gbs
BER=<10^-12
Electrical Interface
Characteristics
Parameter
Symbol
Min.
Typ.
Max.
Unit
Note
Total power supply current
Icc
-
450
mA
Transmitter
Differential Data Input Voltage
VDT
180
-
700
mVp-p
Differential line input Impedance
RIN
85
100
115
Ohm
Transmitter Fault Output-High
VFaultH
2.4
-
Vcc
V
Transmitter Fault Output-Low
VFaultL
-0.3
-
0.8
V
Transmitter Disable Voltage- High
VDisH
2
-
Vcc+0.3
V
Transmitter Disable Voltage- low
VDisL
-0.3
-
0.8
V
Receiver
Differential Data Output Voltage
VDR
300
-
850
mVp-p
Differential line Output Impedance
ROUT
80
100
120
Ohm
Receiver LOS Pull up Resistor
RLOS
4.7
-
10
KOhm
Data Output Rise/Fall time
tr/tf
-
38
ps
LOS Output Voltage-High
VLOSH
2
-
Vcc
V
LOS Output Voltage-Low
VLOSL
-0.3
-
0.4
V
