HWUV0133X three-dimensional UV UV curing box,it is a multi-functional three-dimensional, three-dimensional, multi-faceted UV curable box suitable for mass production.Without ultraviolet leaks,it can protect human body from ultraviolet radiation, rotate tray automatically, solidify thoroughly, irradiate at all angles and without irradiation blind area.The system consists of three parts: manual shutter system, mobile light source and curing box.Because of its simple design, it is very good and reliable. It does not require any training and setting time. This system is ideal for the curing applications that often need to be moved. It is suitable for curing UV inks, UV coatings, UV varnishes, adhesives and sealing materials, as well as crystal jadeite jewelry light curing inlay process.

Characteristic:

Equipment comPOSTTTION

Light box (deformable to hand-held light source) + curing box + automatic turntable + power box (optional electronic power supply)

Modular design

The box type UV light source is modular design,can be used in hand-held, fixed and box type.

Movable UV lamp

The hand-held light source contains a long life high pressure mercury lamp, emitting UVA (300-400nm), and the main light intensity distribution is uniform. The life span of the bulb is 1000 hours. The lamp holder is connected to the main power supply box by a soft wire for easy movement or installation on a customer's fixture, conveyor belt or automation machine.

UV curing box

The equipment consists of a curing box with a box door, and the switch is very convenient. During the curing process of the component, it can protect the user from ultraviolet radiation.

Built in shading manual shutter (no UV leak at work)

The device integrates a retractable and light-shielded manual shutter to ensure good repeatability of curing and to protect the user from UV radiation when switching the curing box door.

Adjustable speed automatic rotating tray

The equipment has an automatic rotating tray that can adjust the speed. The curing effect is better and more thorough.Three dimensional UV photocurable can finish multi-dimensional curing and three-dimensional solidification at one time.

The inner wall of the reflective light

The reflector inner wall structure and the optimized reflector can ensure the uniform irradiation effect.

Forced air cooling system

Light source, power supply and curing box all integrate cooling fan, which makes the system work in a good heat dissipation environment and increases the reliability of the system.

Selection of lamp power:

600W lamp, 1000W lamp, 1500W lamp, metal halide lamp, and electronic power supply.
