防眩光羽毛球馆灯30W40W50W60W80W70W100W120W150W200W250W300WLED防水 防尘 防爆 游泳馆照明灯 防腐工矿灯 LED羽毛球馆灯 LED场馆灯 LED游泳馆灯

型号

Type

KW-GS60W

KW-GS80W

KW-GS100W

KW-GS120W

KW-GS150W

KW-GS200W

KW-GS250W

KW-GS300W

功率

Power

60W

80W

100W

120W

150W

200W

250W

300W

输入电压

Input voltage

AC85-305V 480-528V DC12/24/36/48V

电源频率

Freqency range

50-60Hz

发光效率

luminous efficiency

100-110lm/w

灯具效率

Lamp>s efficiency

>90%

相关色温

Color temperature

暖白 Warm white

2700-3500K

正白 Pure white

4000-5000K

冷白 Cold white

6000-7000K

显色指数

Color rendering index

>80

光束角

Beam angle

120°

配光曲线

Light distribution

圆形光斑Round spot

配光方式

Light design

LED+透镜LED+lens

LED 结点温升

Junction temperature

≤30℃

工作环境温度

Working temperature

-30℃——+55℃

储藏环境温度

Storage temperature

-25℃——+65℃

防护等级

IP Grade

IP65

光源使用寿命

Working life-span

50000H

灯头

Base

E40、E39、E27、E26

灯具 外壳颜色

Color of lamp shell

黑色 Black

*

Certificate

CE、ROSH、FCC、PSE

采用高导纯铝鳍片散热器，外观阳极氧化，让整体灯具重量更轻，体积更小，Adopt high purity Aluminum finned radiator the fin suce treatment of anodic oxidationlighter weight aller size.

采用原装进口美国科锐/飞利浦灯珠，高显色高光效，亮度可达130LM/W。Adopt CREE /Philips LED chips imported from Americahigh CRI and high efficiency up to 130lm/W.

采用恒流恒压驱动，电源范围85-305VAC，各国电压均可使用 。Adopt Constant-current constant-voltage power supply operates in the 85~305 VAC rangewidely use in every country.

采用进口磁悬浮电脑风扇，噪音小低于5分贝，寿命更长远。Adopt gnetic levitation Company fannoise lower than 5 dblonger lasting .

采用高品质雾面导光片增强漫反射，光色均匀、柔和、无眩光、不刺眼；Adopt high end diffuser high lumen outputsoft light no glare.

可定制调光（0-10/可控硅/DALI） 特殊照明（RGB/应急）Dimming(0-10V/Triac/Dali) and professional lighting(Emergency/RGB) customized available.



防眩光羽毛球馆灯30W40W50W60W80W70W100W120W150W200W250W300WLED防水 防尘 防爆 游泳馆照明灯 防腐工矿灯 LED羽毛球馆灯 LED场馆灯 LED游泳馆灯
