规格说明

1.主电源电压: AC 220V 380-480V ±10%

2.辅助电压: AC 220V±15% 50/60Hz

3.额定电流: 25A-750A

4.工作频率: 47-63Hz

5.输出方式: 相位控制输出

6.相位输入控制讯号: 4-20mA, 0-5V, 1-5V, 0-10V, 2-10V。

型号规格：

三相三线相位控制：适用于变压器与非电阻性负载

JK3PTS-22025, JK3PTS-22035, JK3PTS-22050,JK3PTS-22060, JK3PTS-22080, JK3PTS-22100, JK3PTS-22125, JK3PTS-22160, JK3PTS-22180, JK3PTS-22200, JK3PTS-22225, JK3PTS-22250, JK3PTS-22300, JK3PTS-22350, JK3PTS-22400, JK3PTS-22600, JK3PTS-22750
JK3PTS-48025, JK3PTS-48035, JK3PTS-48050,JK3PTS-48060, JK3PTS-48080, JK3PTS-48100, JK3PTS-48125, JK3PTS-48160, JK3PTS-48180, JK3PTS-48200, JK3PTS-48225, JK3PTS-48250, JK3PTS-48300, JK3PTS-48350, JK3PTS-48400, JK3PTS-48600, JK3PTS-48750
