MASTER  TL-D  90  De  Luxe  36W/965  1SL

低压汞放电灯，配备管状26毫米的封装。

一般特性

灯头座                                                                    G13  [中型双针荧光灯]

玻壳                                                                        T8  [26  mm]

50％失效时寿命(配电感镇流器)                                15000  hr

50％失效时寿命(配预热启动式电子镇流器)      20000  hr

50％失效时寿命(配非预热启动式电子镇流器)  12000  hr

10％失效时寿命(配非预热启动式电子镇流器)  10000  hr

10％失效时寿命(配预热启动式电子镇流器)      17000  hr

寿命至10％故障率，EM                                                      12000  hr

LSF场致发光片,额定12000小时，3小时循环    90  %

LSF场致发光片,额定8000小时，3小时循环      95  %

LSF场致发光片,额定6000小时，3小时循环    96  %

LSF场致发光片,额定4000小时，3小时循环    97  %

LSF场致发光片,额定2000小时，3小时循环    99  %



电气特性

额定光源功率                                                            36  W

可调光                                                                        Yes

光源电流，场致发光片25°C                                                0.440  A

光源功率，EM  25°C，额定                                                36.0  W

光源功率，电磁25°C，标称                                    36  W

光源电压，场致发光片25°C                                                  103  V



环境特性

能源效率标识(EEL)                                                                      B

汞（Hg）含量                                                                5.0  mg



照明灯技术特性

色标                                                                                                          965  [CCT  of  6500K]

显色指数                                                                                                93  Ra8

颜色描述（文字）                                                      冷日光

色温                                                                              6500  K

色度坐标X                                                                                          309  -

色度坐标Y                                                                                            322  -

平均亮度EM                                                                                        1.00  cd/cm2

照明效率,额定场致发光片25°C                                      77.8  Lm/W

LLMF场致发光片,额定12000小时                                90  %

LLMF场致发光片,额定8000小时                                    93  %

LLMF场致发光片,额定6000小时                                    94  %

LLMF场致发光片,额定4000小时                                    95  %

LLMF场致发光片,额定2000小时                                    96  %

光通量，场致发光片25°C，额定                            2800  Lm

光通量，场致发光片25°C，标称                          2800  Lm

设计温度                                                                      25  C



产品尺寸

基座面与基座面A                                                                            1199.4  mm

插入长度B                                                                                            1204.1  (min),  1206.5  (max)  mm

总长C                                                                                                    1213.6  mm

直径D                                                                                                      28  mm
