N9020B信号分析仪租赁N9020B keysight N9020B 是德N9020B N9020B

• 快速适应无线器件不断演进的测试要求
• 通过硬件加速功率测量缩短测试时间，显示更新速率快，并且具有游标峰值搜索和快速扫描功能
• X 系列应用软件提供一键式测量，显著简化测试
• 全频段实时频谱分析能够捕获偶发或瞬态信号

• Frequency range
  N9020B-503	Frequency Range, 10 Hz to 3.6 GHz
  N9020B-508	Frequency Range, 10 Hz to 8.4 GHz
  N9020B-513	Frequency Range, 10 Hz to 13.6 GHz
  N9020B-526	Frequency Range, 10 Hz to 26.5 GHz
  N9020B-532	Frequency Range, 10 Hz to 32 GHz
  N9020B-544	Frequency Range, 10 Hz to 44 GHz
  N9020B-550	Frequency Range, 10 Hz to 50 GHz
  Preamplifier
  N9020B-P03	Preamplifier, 3.6 GHz
  N9020B-P08	Preamplifier, 8.4 GHz
  N9020B-P13	Preamplifier, 13.6 GHz
  N9020B-P26	Preamplifier, 26.5 GHz
  N9020B-P32	Preamplifier, 32 GHz
  N9020B-P44	Preamplifier, 44 GHz
  N9020B-P50	Preamplifier, 50 GHz
  Bandwidth
  N9020B-B1A	Analysis Bandwidth, 125 MHz
  N9020B-B1X	Analysis Bandwidth, 160 Mhz
  N9020B-B40	Analysis Bandwidth, 40 MHz
  N9020B-B85	Analysis Bandwidth, 85 MHz
  Performance Options
  N9020B-FT2	Frequency Mask Trigger, Optimum Detection License
  N9020B-MPB	Microwave Preselector Bypass
  N9020B-NF2	Noise Floor Extension
  N9020B-PFR	Precision Frequency Reference
  N9020B-TDS	Time Domain Scan
  N9020B-DP2	Deep Capture Memory
  N9020B-EA3	Electronic Attenuator, 3.6 GHz, Upgrade
  N9020B-EDP	Enhanced Display Package License
  N9020B-EMC	Basic EMC Functionality License
  N9020B-FP2	Fast Power, Up To 40 MHz Bandwidth
  N9020B-FT1	Frequency Mask Trigger, Basic Detection License
  N9020B-RBE	Resolution Bandwidth Extended
  Baseband Inputs
  N9020B-BBA	I/Q Baseband Inputs, Analog
  Calibration Options
  N9020B-AMG	Calibration + Uncertainties + Guardbanding (Accredited)
  N9020B-A6J	ANSI Z540-1-1994 Calibration
  N9020B-UK6	Commercial Calibration Certificate with Test Data
  Connection Options
  N9020B-CR3	Connector, Wideband IF Output
  N9020B-CRP	Connector, Programmable Rear IF Output
  N9020B-YAS	Y-Axis Ouptut
  External Mixing
  N9020B-EXM	External Mixing
  Real time signal analysis
  N9020B-RT1	Real-time analysis up to maximum available BW, basic detection license
  N9020B-RT2	Real-time analysis up to maximum available BW, optimum detection license
  Portable Packaging
  N9020B-PRC	Portable Configuration
  Security - PC features
  N9020B-SF2	Security Features, Prohibit Saving Results
  N9020B-SSD	Additional Removable Solid State Drive
  N9020B-SF1	Security Features, Exclude Launching Programs
  N9020B-SS1	Additional removable solid state drive, Win10
  Source Connectivity
  N9020B-ESC	External Source Control License
  Application software
  89601B	- 89600 VSA 软件
  N6171A	MATLAB 软件
  N9063C	模拟解调测量应用软件，多点触控用户界面
  N9068C	相位噪声测量应用软件，多点触控用户界面
  N9069C	噪声系数测量应用软件，多点触控用户界面
  N9071C	GSM / EDGE / Evo Measurement Application, Multi-Touch UI
  N9073C	W-CDMA/HSPA/HSPA+ Measurement Application, Multi-touch UI
  N9077C	WLAN 802.11a/b/g/j/p/n/ac/af/ah/ax Measurement Application, Multi-Touch UI
  N9080C	LTE/LTE-Advanced FDD 测量应用软件，多点触控用户界面
  N9082C	LTE / LTE-Advanced TDD Measurement Application, Multi-touch UI
  N9081C	Bluetooth Measurement Application, Multi-Touch UI
  N9084C	Short Range Communications Measurement Application, Multi-Touch UI
  N9067C	脉冲测量应用软件，多点触控用户界面
  N6141C	EMI 测量应用软件，多点触控用户界面
  N9054C	VMA 矢量调制分析应用软件，多点触控用户界面
  N9061C	Remote Language Compatibility Application, Multi-Touch UI
  N9062C	SCPI Language Compatibility Application, Multi-touch UI
  Real Time Recorder
  N9020B-RTR	Real-Time Spectrum Recorder And Analyzer Application Example, License
  Accessories
  1CM113A	Rack mount flange kit 177.0mm H (4U) - two flange brackets, 2015 color
  1CN103A	Handle kit 177.0mm H (4U) - two front handles, 2015 color
  1CP105A	Rack mount flange and handle kit 177.0mm H (4U) - two brackets and front handles
  1DVR001A	ROM/CD-R/RW drive
  1KBD001A	USB keyboard-smaller keyboard
  1MSE001A	Mouse
  MLP001A	Minimum loss pad, 50 to 75 ohm
  1CR013A	Rack Slide Kit for 11in, 14in, and 16in Mounting Holes
  Additional Documentation
  N9020B-AB1	Korean localization, user interface and getting started guide
  N9020B-AB2	Chinese localization, user interface and getting started guide
  N9020B-ABE	Spanish localization, user interface and getting started guide
  N9020B-ABF	French localization, user interface and getting started guide
  N9020B-ABJ	Japanese localization, user interface and getting started guide
  N9020B-AKT	Russian localization, user interface and getting started guide
  Application Software with SubSCRJPTion
  N6141EM0E	EMI Measurement Application
  N9061EM0E	Remote Language Compatibility Measurement Application
  N9077EM0E	WLAN 802.11a/b/g/j/p/n/af/ah Measurement Application
  N9062EM0E	SCPI Language Compatibility Measurement Application
  N9063EM0E	Analog Demodulation Measurement Application
  N9067EM0E	Pulse Analysis Measurement Application
  N9068EM0E	Phase Noise Measurement Application
  N9069EM0E	Noise Figure Measurement Application
  N9071EM0E	GSM/EDGE/Evo Measurement Application
  N9073EM0E	W-CDMA/HSPA+ Measurement Application
  N9077EM1E	WLAN 802.11a/b/g/j/p/n/af/ah Measurement Application
  N9080EM0E	LTE and LTE-Advanced FDD Measurement Application
  N9080EM3E	NB-IoT and eMTC FDD Measurement Application
  N9081EM0E	Bluetooth (TM) Measurement Application
  N9082EM0E	LTE and LTE-Advanced TDD Measurement Application
  N9084EM0E	Short Range Communications Measurement Application
  N9085EM0E	5G NR Measurement Application
  N9020RT1B	Real-time analysis up to maximum available BW, Basic Detection
  N9020RT2B	Real-time analysis up to maximum available BW, Optimum Detection
  N90EMEDPB	Enhance Display Package
  N90EMEMCB	Basic EMC Functionality
  N90EMESCB	External Source Control
  N90EMFP2B	Fast Power Up to 40 MHz
  N90EMFT1B	Frequency Mask Trigger, Basic Detection
  N90EMFT2B	Frequency Mask Trigger, Optimum Detection
  N90EMTDSB	Time Domain Scan
  N9054EM0E	VMA Vector Modulation Analysis Measurement Application
  N9054EM1E	Vector Modulation Analysis Custom OFDM Application
  N90EMRBEB	Resolution Bandwidth Extended
