K9平凹柱面镜/平凹柱面镜/平凹柱面透镜
K9平凹柱面透镜
K9平凹柱面镜/平凹柱面镜/平凹柱面透镜
K9平凹柱面透镜 (尺寸及镀膜可按用户需求定制)单位(mm)
K9平凹柱面镜/平凹柱面镜/平凹柱面透镜
材??料:H-K9L
设计波长:587.6nm
焦距公差:±1%
外形公差:+0.0/-0.1mm
厚度公差:±0.2mm
面??型:λ/2@632.8nm
光 洁 度:60-40
偏??心:<3'
有效孔径:>90%
倒??边:<0.2×45°
镀??膜:多层增透膜 A:350-650nm B:650-1050nm C:1050-1580n
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1395L1S
-3.90
6.00
4.00
-2.02
2.00
2.70
-5.22
21K1395L2S
-3.90
8.00
4.00
-2.02
2.00
2.70
-5.22
21K1597L1S
-4.00
6.00
4.00
-2.07
2.00
2.60
-5.32
21K1597L2S
-4.00
8.00
4.00
-2.07
2.00
2.60
-5.32
21K1523L1S
-5.80
6.00
4.00
-3.00
2.00
2.40
-7.12
21K1523L2S
-5.80
8.00
4.00
-3.00
2.00
2.40
-7.12
21K1087L1S
-6.40
8.00
6.00
-3.31
2.00
3.20
-7.72
21K1087L2S
-6.40
12.00
6.00
-3.31
2.00
3.20
-7.72
21K1363L1S
-7.70
9.00
7.00
-3.98
2.00
3.40
-9.02
21K1363L2S
-7.70
14.00
7.00
-3.98
2.00
3.40
-9.02
21K1836L1S
-9.70
12.00
10.00
-5.01
2.00
4.80
-11.02
21K1836L2S
-9.70
20.00
10.00
-5.01
2.00
4.80
-11.02
21K1684L1S
-12.70
12.00
10.00
-6.56
2.00
3.80
-14.02
21K1684L2S
-12.70
20.00
10.00
-6.56
2.00
3.80
-14.02
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1816L1S
-13.70
15.00
13.00
-7.08
2.00
5.30
-15.02
21K1816L2S
-13.70
26.00
13.00
-7.08
2.00
5.30
-15.02
21K1753L1S
-15.00
12.00
10.00
-7.75
2.00
3.40
-16.32
21K1753L2S
-15.00
20.00
10.00
-7.75
2.00
3.40
-16.32
21K1037L1S
-19.00
21.00
19.00
-9.82
2.00
7.90
-20.32
21K1037L2S
-19.00
38.00
19.00
-9.82
2.00
7.90
-20.32
21K1085L1S
-20.00
17.00
15.00
-10.34
2.00
4.70
-21.32
21K1085L2S
-20.00
30.00
15.00
-10.34
2.00
4.70
-21.32
21K1006L1S
-22.20
15.00
12.50
-11.47
2.00
3.50
-23.52
21K1006L2S
-22.20
25.00
12.50
-11.47
2.00
3.50
-23.52
21K1426L1S
-25.00
12.00
10.00
-12.92
2.00
2.80
-26.32
21K1426L2S
-25.00
20.00
10.00
-12.92
2.00
2.80
-26.32
21K1900L1S
-25.40
18.00
16.00
-13.13
2.00
4.40
-26.72
21K1900L2S
-25.40
32.00
16.00
-13.13
2.00
4.40
-26.72
21K1787L1S
-25.40
28.00
25.40
-13.13
2.00
10.30
-26.72
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1787L2S
-25.40
51.00
25.40
-13.13
2.00
10.30
-26.72
21K1982L1S
-30.00
22.00
20.00
-15.50
2.00
5.30
-31.32
21K1982L2S
-30.00
40.00
20.00
-15.50
2.00
5.30
-31.32
21K1325L1S
-38.10
28.00
26.00
-19.69
2.00
6.50
-39.42
21K1325L2S
-38.10
52.00
26.00
-19.69
2.00
6.50
-39.42
21K1283L1S
-40.00
12.00
10.00
-20.67
2.00
2.50
-41.32
21K1283L2S
-40.00
20.00
10.00
-20.67
2.00
2.50
-41.32
21K1662L1S
-50.00
22.00
20.00
-25.84
2.00
3.80
-51.32
21K1662L2S
-50.00
40.00
20.00
-25.84
2.00
3.80
-51.32
21K1336L1S
-50.00
32.00
30.00
-25.84
2.00
6.50
-51.32
21K1336L2S
-50.00
60.00
30.00
-25.84
2.00
6.50
-51.32
21K1792L1S
-50.80
53.00
50.80
-26.25
2.00
19.90
-52.12
21K1792L2S
-50.80
90.00
50.80
-26.25
2.00
19.90
-52.12
21K1995L1S
-60.00
32.00
30.00
-31.01
2.00
5.60
-61.32
21K1995L2S
-60.00
60.00
30.00
-31.01
2.00
5.60
-61.32
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1015L1S
-60.00
62.00
60.00
-31.01
2.00
23.50
-61.32
21K1015L2S
-60.00
95.00
60.00
-31.01
2.00
23.50
-61.32
21K1216L1S
-62.90
53.00
50.80
-32.51
2.00
13.60
-64.22
21K1216L2S
-62.90
95.00
50.80
-32.51
2.00
13.60
-64.22
21K1913L1S
-70.00
32.00
30.00
-36.18
2.00
5.00
-71.32
21K1913L2S
-70.00
60.00
30.00
-36.18
2.00
5.00
-71.32
21K1431L1S
-75.00
53.00
50.80
-38.76
2.00
11.10
-76.32
21K1431L2S
-75.00
90.00
50.80
-38.76
2.00
11.10
-76.32
21K1689L1S
-75.60
53.00
50.80
-39.07
2.00
12.00
-77.58
21K1689L2S
-75.60
90.00
50.80
-39.07
2.00
12.00
-77.58
21K1526L1S
-80.00
22.00
20.00
-41.34
2.00
4.10
-81.98
21K1526L2S
-80.00
40.00
20.00
-41.34
2.00
4.10
-81.98
21K1310L1S
-80.00
82.00
80.00
-41.34
3.00
32.10
-81.98
21K1310L2S
-80.00
145.00
80.00
-41.34
3.00
32.10
-81.98
21K1743L1S
-100.00
32.00
30.00
-51.68
3.00
5.10
-101.98
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1743L2S
-100.00
60.00
30.00
-51.68
3.00
5.10
-101.98
21K1936L1S
-100.00
90.00
100.00
-51.68
3.00
39.90
-101.98
21K1936L2S
-100.00
145.00
100.00
-51.68
3.00
39.90
-101.98
21K1819L1S
-130.00
32.00
30.00
-67.18
3.00
4.60
-131.98
21K1819L2S
-130.00
60.00
30.00
-67.18
3.00
4.60
-131.98
21K1419L1S
-150.00
32.00
30.00
-77.52
3.00
4.40
-151.98
21K1419L2S
-150.00
60.00
30.00
-77.52
3.00
4.40
-151.98
21K1956L1S
-150.00
90.00
100.00
-77.52
3.00
20.90
-151.98
21K1956L2S
-150.00
145.00
100.00
-77.52
3.00
20.90
-151.98
21K1069L1S
-200.00
32.00
30.00
-103.36
3.00
4.00
-201.98
21K1069L2S
-200.00
60.00
30.00
-103.36
3.00
4.00
-201.98
21K1115L1S
-200.00
90.00
100.00
-103.36
3.00
15.60
-201.98
21K1115L2S
-200.00
145.00
100.00
-103.36
3.00
15.60
-201.98
21K1030L1S
-250.00
32.00
30.00
-129.20
3.00
3.80
-251.98
21K1030L2S
-250.00
60.00
30.00
-129.20
3.00
3.80
-251.98
编号(NO.)
焦距(EFL)
长(L)
宽(H)
半径(R)
中心厚(Tc)
边厚(Te)
后焦距(BFL)
21K1984L1S
-300.00
62.00
60.00
-155.04
3.00
5.80
-301.98
21K1984L2S
-300.00
95.00
60.00
-155.04
3.00
5.80
-301.98
21K1487L1S
-400.00
32.00
30.00
-206.72
3.00
3.50
-401.98
21K1487L2S
-400.00
60.00
30.00
-206.72
3.00
3.50
-401.98
21K1281L1S
-500.00
32.00
30.00
-258.40
3.00
3.40
-501.98
21K1281L2S
-500.00
60.00
30.00
-258.40
3.00
3.40
-501.98
21K1220L1S
-700.00
32.00
30.00
-361.76
3.00
3.30
-701.98
21K1220L2S
-700.00
60.00
30.00
-361.76
3.00
3.30
-701.98
21K1002L1S
-1000.00
32.00
30.00
-516.80
3.00
3.20
-1001.98
21K1002L2S
-1000.00
60.00
30.00
-516.80
3.00
3.20
-1001.98
04
16
2024
CYLPCV-K9 K9平凹柱面镜/平凹柱面镜/平凹柱面透镜 柱透镜
来源:[长春市金龙光电科技有限责任公司]
联系人：徐先生
手机：13504313329
电话：0431-85353336
传真：0431-80812838
QQ：153303898
Email：wlxu@GoldDragonOptics.com
地址：吉林省长春市长春市高新技术开发区越达路888号越达科技产业园17栋
品牌：长春金龙
价格：100.00
元/片
供应地：吉林省长春市
产品型号：CYLPCV-K9
