Capacity

量程

1-5T

sensitivity

灵敏度

1.0-2.0mv/v

Optional transmit

可加变送输出

0-5V 、0-10V、 4-20MA、RS485/232

Zero Balance

零点平衡

±1% of rated output

Creep after 30 minutes

蠕变

±0.3% of rated output

Nonlinearity

非线性

±0.3% of rated output

Repeatability

重复性

±0.2% of rated output

Temp. effect on output

灵敏度温漂

≤0.02% of applied output/oC

Temp. effect on zero

零点温漂

≤0.02% of applied output/oC

Safe Temp. Range

可用温度范围

-20oC to + 60oC

Temp. Compensated

温度补偿范围

-10oC to + 40oC

Safe Overload

安全载荷

120%

limit load

极限载荷

150%

Input Impedance

输入阻抗

380 ohm ± 20 ohm

Output Impedance

输出阻抗

350 ohm ± 5 ohm

Rated Excitation

推荐激励电压

10V DC/AC

Maximum Excitation

最大激励电压

15V DC/AC

Frequency response

响应频率

≤20KHZ

For reference only, the actual parameters shall be subject to factory calibration certificate!          仅做参考，实际参数以出厂标定合格证书为准！
