Rated load

额定载荷

0.2-25T

sensitivity

灵敏度

1.0-2.0mv/v

Optional transmit

变送输出

0-5V 、0-10V、 4-20mA、RS485/232

Zero Balance

零点平衡

±1% of rated output

Creep after 30 minutes

蠕变

±0.3% of rated output

Nonlinearity

非线性

±0.3% of rated output

Repeatability

重复性

±0.2% of rated output

Temp. effect on output

灵敏度温漂

≤0.02% of applied output/oC

Temp. effect on zero

零点温漂

≤0.02% of applied output/oC

Safe Temp. Range

可用温度范围

-20oC to + 60oC

Temp. Compensated

温度补偿范围

-10oC to + 40oC

Safe Overload

安全载荷

120%

limit load

极限载荷

150%

Input Impedance

输入阻抗

380 ohm ± 20 ohm

Output Impedance

输出阻抗

350 ohm ± 5 ohm

Rated Excitation

推荐激励电压

10V DC/AC

Maximum Excitation

最大激励电压

15V DC/AC

Frequency response

响应频率

≤20KHZ

SCHEMATIC  连接方式

Red: +input      红色：+激励

Green: +output    绿色：+信号

Black: -input     黑色：-激励

White: -output    白色： -信号
