HP4339A HP 4339A Agilent4339A 高阻测试仪

本公司诚恳希望这条信息能帮助到您！


本公司是专业回收（销售）二手仪器仪表公司，如果你需要采购

或者出售什么产品的话，我们有专业的客服经理为您提供服务

一个电话马上为您报价,顾客至上,诚信买卖,思迈仪器段S


东莞市思迈电子仪器有限公司

段海英：13539016670         回收工厂闲置/倒闭电子仪器，个人处理仪器，欢迎来电！！

Q    Q：593433036           回收工厂闲置/倒闭电子仪器，个人处理仪器，欢迎来电！！

邮  箱: 593433036@qq.com    回收工厂闲置/倒闭电子仪器，个人处理仪器，欢迎来电！！


HP4339A HP 4339A Agilent4339A 高阻测试仪

Wide measurement range: 1 x 103 ohm to 1.6 x 1016ohm
Stable test fixtures: resistivity cell, component test fixture
High-speed measurement: 10 ms
Test sequence programming
Resistivity calculations
Grounded DUT measurement
Specifications
Measurement Functions
Measurement Parameters: R (dc resistance), I (dc current), rs (surface resistivity), rv (volume resistivity)
Mathematical Functions: Deviation and percent deviation
Ranging: Auto and manual
Trigger: Internal, external, manual, and HP-IB
Delay Time: 0 to 9999 ms in 1 ms steps
Test Cable Lengths: 2 m maximum
Measurement Time: Short, medium, and long
Averaging: 1 to 256
Test Voltage: 0 to 1000 Vdc, 100 mV steps @ 0 to 200 V, 1 V steps @ 200 to 1000 V
Maximum Current: 10 mA @ < 100 v, 5 ma @ < 250v, 2 ma @ < 500 v, 1 ma @ < 1 kv <>
Current Compliance Setting: 0.5 mA, 1 mA, 2 mA, 5 mA, 10 Ma
