ID Type外觀

True Flat  Metal,平面式外观

Panel spec
面板規格

Type類型

IPS

Resolution分辨率

1920(H)x1080(V)

Active Screen Size面板尺寸(inch)

26

Display Area可视图像大小(mm)

573(H)x324(V)

Pixel Pitch像素(mm)

0.3(H)x0.3(V)

Viewing Angel可视角度(degree)

178(H)/178(V)

Response Time反應時間(ms)

18(typ.)

Brightness亮度(nits)

450(typ.)

Contrast Ratio对比度

1400:1(typ.)

Backlight背光技术

Edge LED Type

NTSC 色域(%)

NTSC 72%

Rx / Ry

0.655/0.330

Gx / Gy

0.305/0.615

Bx /By

0.150/0.060

Wx / Wy

0.300/0.335

Display Colors色彩(bits)

10

 I/O Interface
輸入/輸出接口

DVI

Yes(in x1)

HDMI

Yes(in x1)

DP

Yes(in x1)

VGA

Yes(in x1)

Composite (BNC)(In)(Out)

Yes(in x1 out x1)

S-Video(4pins Mini-Din)(In)(Out)

Yes(in x1 out x1)

RGBS/YPbPr(BNC)(In)(Out)

Yes(in x5 out x3)

3G-SDI(BNC)(In)(Out)

Yes(in x1 out x1)

Serial Remote控制接口

RS232(D-sub 9pin)

IR Remote Control 紅外線遙控

NA

Features產品特性

Color Temp 色溫

Nautral/6500K/7500K/8200K/9300/User

Gamma Selection 伽馬

Native/1.8/2.0/2.2/DICOM

OSD Languages 菜單语言

English/Spanish/French/German/Italian/S.Chinese /Japan

PIP/ PAP 畫面佈局設定

PIP/PAP

Scaling OverScan 變焦模式

Full Screen/Aspect Ratio/Native

User Color Adjust 色彩调整

R Gain/G Gain/B Gain

HDMI Video Format视频模式

(Auto/YCbCr 4:4:4/YCbCr 4:2:2/ RGB)

Gamma LUT Table 灰階度(bits)

10

医疗影像显示模式

用户模式/文字模式/DICOM CL/DICOM BL/灯箱模式

Power Requirements
電源管理

Power Supply電源種類

Input 100-240V,50-60Hz, Output 24VDC, ±5%,3.75A,医规电源IEC60601-1

Power Consumption耗電量(W)

72(Max)

Physical characteristics
外觀特色

Protective film 保护装置

厚度 3.0±0.3,透光率 98%

Surface Treatment

AR抗反射镀膜玻璃

Dimensions(W×H×D)外觀尺寸(mm)

651 x 402 x 98.2(w/o Stand)

Weight重量(Kg)

8.2 (w/o Stand)

Color 顏色

GE N9 White

IPxx防水等級

前框 IPX 5,后盖IPX1

VESA Mounting壁掛孔位(mm)

100x100200x100

Reliability
可靠度

Operating Temperature 操作温度(℃)

10 to 40

Operating Humidity 操作濕度(RH)

30% to 75%

Storage Temperature 儲存温度(℃)

-20 to 60

Storage Humidity 儲存温度(RH)

10% to 90%

Certifications and Compliances認證與安規

cTUVus(ANSI/AAMI ES 60601-1, CAN/CSA C22.2No. 60601-1),CB(60950/60601),CE,FCC ClassB part 15
CCC,VCCI, BSMI
