Specifications

Accuracy

Rated capacity(R.C.)

50kgf, 100kgf, 200kgf, 500kgf, 1tf, 2tf, 5tf, 10tf (490.3N, 980.7N, 1.961kN, 4.903kN, 9.807kN, 19.61kN, 49.03kN, 98.07kN)

Rated output(R.O.)

2mV/V±0.4%

Nonlinearity

0.15% of R.O.

Hysteresis

0.1% of R.O.

Repeatability

0.05% of R.O.

Zero balance

±2% of R.O.

Temperature effect, on rated output

0.1% of R.O./10℃

Temperature effect, on zero balance

0.05% of R.O./10℃

Temperature range, compensated

-10~70℃

Temperature range, safe

-20~80℃

Terminal resistance input

350 ±50Ω

Terminal resistance output

350 ±2Ω

Insulation resistance bridge/case

2000MΩ

Excitation recommended

10V

Safe overload

150% R.C

Cable length

Φ5mm 4core,3m
