C-FLEX轴承，cflex轴承，H-10 20 30轴承，进口磨床轴承。
挠性轴承，十字轴承，弯曲轴承，角度轴承，柔性铰链 C-Flex pivot bearing,Single end bearing
由于数量多少，价格相差很大，欢迎咨询。
WALDRICH磨床备件号：7-0502494 5/8 DIA 15.88X25.4
12.8630.00851 测量设备 7.0502494 自由弯曲枢轴5020/600(5020-600) 5/8" Dia. 15.88X25.4
单位（Inch,Lb,Lb-In/Degree)
示例：
HD-10中间弹片厚度0.007in=0.173mm
HD-20中间弹片厚度0.014in=0.345mm
HD-30中间弹片厚度0.027in=0.691mm
Product Codes:All the Single End Bearings from C-flex company
Dia.
1/8
5/32
3/16
1/4
5/16
3/8
1/2
5/8
3/4
1
10系列
AD-10
BD-10
CD-10
DD-10
ED-10
FD-10
GD-10
HD-10
ID-10
JD-10
20系列
AD-20
BD-20
CD-20
DD-20
ED-20
FD-20
GD-20
HD-20
ID-20
JD-20
30系列
AD-30
BD-30
CD-30
DD-30
ED-30
FD-30
GD-30
HD-30
ID-30
JD-30
C-Flex Bearings
Bearing Sizes
Product Codes
Torsional Spring Rate(1)
Load (2)
Capacity (2)
Dia.
+0
A
C
D
1/8
AD-10
.0003
2.30
4.60
.1250
.200
.038
.070
1/8
AD-20
.0018
17.50
25.00
.1250
.200
.038
.070
1/8
AD-30
.0148
28.00
28.00
.1250
.200
.038
.070
5/32
BD-10
.0004
3.50
7.00
.1562
.250
.050
.100
5/32
BD-20
.0037
28.00
40.00
.1562
.250
.050
.100
5/32
BD-30
.0296
45.00
45.00
.1562
.250
.050
.100
3/16
CD-10
.0007
5.00
10.00
.1875
.300
.060
.120
3/16
CD-20
.0060
40.00
60.00
.1875
.300
.060
.120
3/16
CD-30
.0482
63.00
63.00
.1875
.300
.060
.120
1/4
DD-10
.0018
9.00
18.00
.250
.400
.083
.165
1/4
DD-20
.0148
70.00
100.00
.250
.400
.083
.165
1/4
DD-30
.1185
115.00
115.00
.250
.400
.083
.165
5/16
ED-10
.0037
14.00
28.00
.3125
.500
.105
.210
5/16
ED-20
.0296
110.00
150.00
.3125
.500
.105
.210
5/16
ED-30
.2367
175.00
175.00
.3125
.500
.105
.210
3/8
FD-10
.0065
20.00
40.00
.3750
.600
.128
.255
3/8
FD-20
.0482
160.00
220.00
.3750
.600
.128
.255
3/8
FD-30
.4002
250.00
250.00
.3750
.600
.128
.255
1/2
GD-10
.0148
35.00
70.00
.5000
.800
.173
.345
1/2
GD-20
.1185
280.00
380.00
.5000
.800
.173
.345
1/2
GD-30
.9486
450.00
450.00
.5000
.800
.173
.345
5/8
HD-10
.0296
55.00
110.00
.6250
1.000
.210
.430
5/8
HD-20
.2367
450.00
620.00
.6250
1.000
.210
.430
5/8
HD-30
1.8940
700.00
700.00
.6250
1.000
.210
.430
3/4
ID-10
.0482
80.00
160.00
.7500
1.200
.263
.520
3/4
ID-20
.4002
630.00
900.00
.7500
1.200
.263
.520
3/4
ID-30
3.2610
1000.00
1000.00
.7500
1.200
.263
.520
1
JD-10
.1185
140.00
280.00
1.000
1.600
.363
.720
1
JD-20
.9486
1100.00
1500.00
1.000
1.600
.363
.720
1
JD-30
7.8023
1800.00
1800.00
1.000
1.600
.363
.720
(1) Torsional Spring rates: Lb-In/Degree rates of standard C-Flex bearings generally fall within +/-10% of these values at zero load. Contact C-Flex if specific spring rates or closer tolerances are required.
(2) Load Capacity: Lt or Lc (Pounds load in tension or comdivssion) These values are maximum loading (weight or static force) at zero deflection. Load requirements, angular deflection and cyclic life must be considered when sizing bearings. Lc is pure radial load creating comdivssive stresses in the spring, while Lt is a pure radial load creating tensile stresses.
1Lb-In/Degree=6.474 Nm/rad
WALDRICH磨床备件号：7-0502494 5/8 DIA 15.88X25.4
12.8630.00851 测量设备 7.0502494 自由弯曲枢轴5020/600(5020-600) 5/8" Dia. 15.88X25.4
进口轴承，
Double End Beari
(Lc)
(Lt)
-0.0005
± 0.003
min
min
02
22
2021
美国原装C-FLEX轴承 磨床床弹性轴承FD-30挠性弹簧
来源:[深圳市利世达科技有限公司]
联系人：祁女士
手机：18124107005
电话：755-23346336(601)
传真：755-23346336
QQ：1576133004
Email：1576133004@qq.com
地址：广东省深圳市深圳市西乡街道宝安大道4018号华丰国际商务大厦13A16
品牌：C-FLEX
价格：面议
元/件
供应地：广东省深圳市
产品型号：FD-30
