CWVC-2  LED铝基板铡刀型分板机

                                                              特点：
                                                                        1、电气混合式设计，双直刀分切，特别适用于分割精密SMD薄板,铝线路板
                                                                        2、铡刀式工作，适用各种厚度PCB，切板行程在2mm以下，绝无操作安全上的顾虑
                                                                        3、将切板时所产生的内应力降至180MPa以下,避免锡裂，防止精密零件受损
                                                                        4、可分切V槽边缘与零件宽度最0.3mm,高度为60mm
                                                                        5、刀具磨损后可免费翻磨
                                                  机器规格

                                                    最大分板长度  450mm
                                                    外形尺寸[长×宽×高]700×300×400m
                                                    分板厚度:  0.3-3.5mm
                                                    工作气压0.50-0.70Mpa干燥气源
                                                    使用电压:220VAC
                                                    机器重量:120kg
