火龙陶瓷纤维纺织品Huolong Ceramic Fiber Textile Product
◎火龙耐高温陶瓷纤维纺织品包括布、绳、带、纱线等制品，是由陶瓷纤维棉、无碱玻璃长丝、耐高温不锈钢合金丝经特殊工艺加工而成，除上述产品外，我们还根据用户对使用温度的要求具体使用条件，提供特殊规格和性能的耐高温纺织品。
Huolong Ceramic Fiber Textiles contain Cloth，Rope，Tape and Yarn and so on，which have been special processed by the ceramic fiber, fiberglass and steel wire. Also, we can manufacture and supp the bastard sizes products as the client demand
产品种类：Product Series：
◎1260陶纤纱线 HLGX-208G1（玻璃丝增强）；HLGX-208G2（钢丝增强）
◎1260陶纤毛条扭绳 HLGX-208H
◎1260陶纤纱线扭绳 HLGX-208D1（玻璃丝加强）；HLGX-208D2（钢丝加强）
◎1260陶纤方编绳 HLGX-208E1（玻璃丝加强）；HLGX-208E2（钢丝加强）
◎1260陶纤圆编绳 HLGX-208C1（玻璃丝加强）；HLGX-208C2（钢丝加强）
◎1260陶纤带 HLGX-208B1（玻璃丝加强）；HLGX-208B2（钢丝加强）
◎1260陶纤布 HLGX-208A1（玻璃丝加强）；HLGX-208A2钢丝加强）
◎1260陶纤管套绳 HLGX-208F
1260 Ceramic fiber yarn HLGX-208G1 (Glass fiber reinforce) HLGX208G2 (Steel wire reinforced)
1260 Ceramic fiber twisted rope(wicker) HLGX-208H
1260 Ceramic fiber twisted rope (yarn) HLGX-208D1 (Glass fiber reinforced) HLGX-208D2 (Steel wire reinforced)
1260 Ceramic fiber square braided rope HLGX-208E1 (Fiber glass reinforced) HLGX-208E2 (Steel wire reinforced)
1260 Ceramic fiber round braided rope HLGX-208C1 (Fiber glass reinforced) HLGX-208C2 (Steel wire reinforced)
1260 Ceramic fiber tap HLGX-208B1 (Fiber glass reinforced); HLGX-208B2 (Steel wire reinforced)
1260 Ceramic fiber cloth HLGX-208A1 (Fiber glass reinforced); HLGX-208A2 (Steel wire reinforced)
1260 Ceramic fiber sleeve HLGX-208F
产品特性：Characteristic:
◎优良的高温强度
◎优良的电绝缘性能
◎优良的抗酸、油、水汽的腐蚀能力
◎低热导率
◎优良的绝热性能
Excellent high-temperature strength
Excellent electric insulation capability
Excellent corrosion resistance to acid, oil and steam
Low thermal conductivity
Excellent thermal insulation capability
典型应用：Application：
◎布 Cloth
高温管道、容器的绝热、热辐射屏蔽、劳保服装、耐高温防火帘、电缆或燃料管道保护、耐高温金属补偿器耐火层、其他工业绝热、保温、耐火及防护绳
Insulation material for high temperature high-temperature tubes and container; the shield for heat radiation, dress for protection of labor, high-temperature safety curtain, protection for cable or fuel tube, flame retardant coating of high temperature metal compensator, and other industrial thermal insulation, heat preservation, fire resistance and protectio
◎绳 Rope
高温管道隔热与密封、电缆绝缘包覆、炼焦炉开口密封、裂解炉砖墙膨胀缝、电炉与烘箱等的炉门密封、锅炉、高温气体密封件密封、柔性膨胀节连接
Insulation of high temperature tubes and containers, etc.; cable insulation twine; the seal of coking furnace opening; the dilatation joint of cracking furnace brick wall; the seal of the doors of electric furnace and oven; the seal of the boiler and hot gas obturator; bind of flexible expansion joint
◎带Tape
工业用隔热、管道及电缆隔热包覆、排气管道隔热包覆、螺栓法兰连接、热辐射屏蔽、高温炉门幕帘
Insulation for the industrial; insulation twine of the air duct, etc.; the flange
coupling of screw bolt; thermal radiation shield; the curtain of high-temperature furnace
◎纱线Yarn
缝纫防火布
Materials for stitching up the fireproof cloth
技术指标Technical Index:
陶瓷纤维布、带制品Ceramic Fiber Products of Cloth, Tap
分类温度
Classification Temperature
1260
产品名称Product
陶瓷纤维布Ceramic Fiber Cloth
陶瓷纤维带 Ceramic Fiber Tape
产品代码Code
HLGX-208A1
HLGX-208A2
HLGX-208B1
HLGX-208B2
使用温度
Service Temperature(℃)
450
1000
450
1000
基本材料Basic material
陶瓷纤维/玻纤加强Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
陶瓷纤维/玻纤加强Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
理论体积密度
Theoretical Density (kg/m3)
500±15
500±30
常规尺寸Specification (mm)
30000×1000/2200×2/3
30000×20/50/75/100×2/3
含水率Moisture Content（%）
≤2
经向密度Warp Density
56-60piece/10cm
纬向密度Weft density
24-30piece/10cm
Organic Content (%)
≤15
陶瓷纤维圆编绳、方编绳制品Ceramic Fiber Round Braided Rope and Square Braided Rope
分类温度
Classification Temperature
1260
产品名称Product
陶纤圆编绳
Ceramic Fiber Round Braided Rope
陶纤方编绳
Ceramic fiber square braided rope
产品代码Code
HLGX-208C1
HLGX-208C2
HLGX-208E1
HLGX-208E2
使用温度Service temperature(℃)
450
1000
450
1000
基本材料Basic material
陶瓷纤维/玻纤加强Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
陶瓷纤维/玻纤加强Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
理论体积密度
Theoretical Density (kg/m3)
600±30；550±30
600±30；550±30
含水率Moisture Content（%）
≤2
交货状态Delivery State
卷状Roll
有机物含量Organic Content (%)
≤15
陶瓷纤维扭绳制品Ceramic Fiber Twisted Rope
分类温度
Classification Temperature
1260
产品名称Product
陶纤纱线扭绳Ceramic Fiber Twisted Rope(yarn)
陶纤毛条扭绳Ceramic fiber Twisted Rope(wicker)
产品代码Code
HLGX-208D1
HLGX-208D2
HLGX-208H
使用温度Service temperature(℃)
450
1000
1000
基本材料Basic Material
陶瓷纤维/玻纤加强Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
陶瓷纤维/玻纤加强
Ceramic fiber/glass fiber reinforced
理论体积密度
Theoretical Density (kg/m3)
500±30
380±50
含水率Moisture Content（%）
≤2
交货状态Delivery State
卷状Roll
有机物含量Organic Content (%)
≤15
陶瓷纤维纱线及管套制品Ceramic Fiber Product of Yarn and Sleeve
分类温度
Classification temperature
1260
产品名称Product
陶纤纱线 ceramic fiber yarn
陶纤套管ceramic fiber sleeve
产品代码Code
HLGX-208G1
HLGX-208G2
HLGX-208F
使用温度Service temperature(℃)
450
1000
1000
基本材料Basic material
陶瓷纤维/玻纤加强
Ceramic fiber/glass fiber reinforced
陶瓷纤维/钢丝加强Ceramic fiber/ stainless steel reinforced
陶瓷纤维/玻纤加强
Ceramic fiber/glass fiber reinforced
理论体积密度
Theoretical density (kg/m3)
纱锭重量Weight of spindle：2±0.2kg
300±50
含水率Moisture content（%）
≤1
交货状态Delivery state
络筒Cheese winding
络筒Cheese winding
卷状Roll
有机物含量Organic content (%)
≤15
≤15
≤2
产品描述：DeSCRJPTion
04
21
2020
陶瓷纤维纺织品 陶瓷纤维布 陶瓷纤维纱线 陶瓷纤维带
来源:[济南火龙热陶瓷有限责任公司]
联系人：崔先生
手机：15764119896
电话：0531-88555918
传真：0531-88559158
QQ：973144813
Email：15764119896@126.com
地址：山东省济南市济南市历下区鲁商国奥城5楼20层
品牌：火龙
价格：35.00
元/公斤
供应地：山东省济南市
产品型号：国标
